DG70000 Series   |  Function / Arbitrary Waveform Generators

DG70000
The DG70000 series is a high-performance arbitrary waveform generator offering banner specifications that include 12 GSa/s sampling rate (interpolated), 5 GHz analog bandwidth, and 1.5 Gpts/CH (or 4 Gpts single channel) waveform length. Additionally, the system provides 16-bit vertical resolution and -70 dBc SFDR (spurious-free dynamic range) for cleaner and purer signal generation. The DG70000 is a feature-rich system, enabling the creation of advanced sequences for user-defined long complex waveforms. It supports high-precision multi-channel synchronization, and the output of high-bandwidth, low-jitter waveforms, making it ready for applications in areas like communications, and scientific research.
Product Feature Customer Benefit
Sample rate from 100 Sa/s to 12 GSa/s User-adjustable sampling provides sample rate from 100 Sa/s to 12 GSa/s, allowing for the reproduction of narrow pulses as low as 400ps.
DC – 5 GHz output frequency range Support for a wider frequency output range grants greater flexibility across a broader selection of signal generation scenarios.
16-bit vertical resolution Market-leading 16-bit vertical resolution delivers finer quantization levels and ensures high-quality signal generation.
Supports 1.5 GHz modulation bandwidth Provides modulation and digital up-conversion, through an IQ modulator, to output various modulation methods (e.g., 1024QAM/256QAM). Can also be combined with built-in frequency hopping mode (frequency hopping interval as low as 128ns), to meet a variety of new broadband wireless standards.
High-quality signal output Performance of -70dBc SFDR, 10 ps total jitter, and 350 fs random jitter ensures a high degree of signal quality for your test application.

Product View

DG70000

Specs

Please scroll to the sides when using small displays
Model Max Output FrequencySample RateVertical ResolutionWaveform Memory DepthChannels Price (CAD)
DG70002 5 GHz5 GSa/s
(12 GSa/s interpolated)
16 bits1.5 Gpts/CH 2 channels Request a Quote
DG70004 5 GHz5 GSa/s
(12 GSa/s interpolated)
16 bits1.5 Gpts/CH 4 channels Request a Quote

 Compare Product Families

To get started using your instruments over the bus download UltraSigma instrument communication software or for older instruments or customized installations review the How to Guide:
Using VISA and drivers to communicate with instruments

For help writing your own programs for our instruments review the programming manual or contact us directly.

Firmware

Drivers

Software

Please scroll to the sides when using small displays

High-speed Serial Function

DG70000-PJ

DG70000 High-speed Serial Function



$13,125

Complex Sequence Function

DG70000-SEQ

DG70000 Complex Sequence Function



$14,358

Please scroll to the sides when using small displays
Please scroll to the sides when using small displays

High-speed Serial Function

DG70000-PJ

DG70000 High-speed Serial Function



$13,125

Complex Sequence Function

DG70000-SEQ

DG70000 Complex Sequence Function



$14,358

DC Amplifier Output

DG70000-DC

DG70000 DC Amplifier Output



$2,850

Digital Up Converter (DUC)

DG70000-DIGUP

DG70000 Digital Up Converter (DUC) and IQ Modulation



$11,344

Multitone & Chirp Mode

DG70000-MTONENL

DG70000 Multitone & Chirp Mode



$8,741

Please scroll to the sides when using small displays
Please scroll to the sides when using small displays
